Bearing Unit NO. |
Shaft Dia d |
Dimensions(mm) |
Bolt Used |
Bearing No. |
Housing No. |
Housing Wt (kg) |
(in) |
(mm) |
a |
e |
i |
s |
z |
Bi |
n |
mm |
in |
UCCF201-8 UCCF202-9 UCCF202-10 UCCF203-11 UCCF204-12 UCCF201 UCCF202 UCCF203 UCCF204 |
1/2 9/16 5/8 11/16 3/4
|
12 15 17 20 |
86 |
64 |
15 |
12 |
46 |
31 |
12.7 |
M10 |
3/8 |
UC201-8 UC202-9 UC202-10 UC203-11 UC204-12 UC201 UC202 UC203 UC204 |
CF201 CF202 CF203 CF204 |
0.84 |
UCCF205-13 UCCF205-14 UCCF205-15 UCCF205-16 UCCF205 |
13/16 7/8 15/16 1
|
25 |
95 |
70 |
16 |
12 |
51 |
34.1 |
14.3 |
M10 |
3/8 |
UC205-13 UC205-14 UC205-15 UC205-16 UC205 |
CF205 |
1 |
UCCF206-17 UCCF206-18 UCCF206-19 UCCF206-20 UCCF206 |
1-1/16 1-1/8 1-3/16 1-1/4
|
30 |
108 |
83 |
18 |
12 |
55 |
38.1 |
15.9 |
M10 |
3/8 |
UC206-17 UC206-18 UC206-19 UC206-20 UC206 |
CF206 |
1.29 |
UCCF207-20 UCCF207-21 UCCF207-22 UCCF207-23 UCCF207 |
1-1/4 1-5/16 1-3/8 1-7/16
|
35 |
117 |
92 |
19 |
14 |
59 |
42.9 |
17.5 |
M12 |
7/16 |
UC207-20 UC207-21 UC207-22 UC207-23 UC207 |
CF207 |
1.61 |
UCCF208-24 UCCF208-25 UCCF208 |
1-1/2 1-9/16
|
40 |
130 |
102 |
21 |
16 |
66 |
49.2 |
19 |
M14 |
1/2 |
UC208-24 UC208-25 UC208 |
CF208 |
2.07 |
UCCF209-26 UCCF209-27 UCCF209-28 UCCF209 |
1-5/8 1-11/16 1-3/4
|
45 |
137 |
105 |
22 |
16 |
67 |
49.2 |
19 |
M14 |
1/2 |
UC209-26 UC209-27 UC209-28 UC209 |
CF209 |
2.42 |
UCCF210-29 UCCF210-30 UCCF210-31 UCCF210-32 UCCF210 |
1-13/16 1-7/8 1-15/16 2
|
50 |
143 |
111 |
22 |
16 |
71 |
51.6 |
19 |
M14 |
1/2 |
UC210-29 UC210-30 UC210-31 UC210-32 UC210 |
CF210 |
2.81 |
UCCF211-32 UCCF211-33 UCCF211-34 UCCF211-35 UCCF211 |
2 2-1/16 2-1/8 2-3/16
|
55 |
162 |
130 |
25 |
19 |
75 |
55.6 |
22.2 |
M16 |
5/8 |
UC211-32 UC211-33 UC211-34 UC211-35 UC211 |
CF211 |
3.56 |
UCCF212-36 UCCF212-37 UCCF212-38 UCCF212-39 UCCF212 |
2-1/4 2-5/16 2-3/8 2-7/16
|
60 |
175 |
143 |
29 |
19 |
86 |
65.1 |
25.4 |
M16 |
5/8 |
UC212-36 UC212-37 UC212-38 UC212-39 UC212 |
CF212 |
4.43 |
UCCF213-40 UCCF213-41 UCCF213 |
2-1/2 2-9/16
|
65 |
187 |
149 |
30 |
19 |
89 |
65.1 |
25.4 |
M16 |
5/8 |
UC213-40 UC213-41 UC213 |
CF213 |
5.37 |
UCCF214-42 UCCF214-43 UCCF214-44 UCCF214 |
2-5/8 2-11/16 2-3/4
|
70 |
193 |
152 |
31 |
19 |
98 |
74.6 |
30.2 |
M16 |
5/8 |
UC214-42 UC214-43 UC214-44 UC214 |
CF214 |
5.72 |
UCCF215-45 UCCF215-46 UCCF215-47 UCCF215-48 UCCF215 |
2-13/16 2-7/8 2-15/16 3
|
75 |
200 |
159 |
34 |
19 |
102 |
77.8 |
33.3 |
M16 |
5/8 |
UC215-45 UC215-46 UC215-47 UC215-48 UC215 |
CF215 |
6.35 |
UCCF216-50 UCCF216 |
3-1/8
|
80 |
208 |
165 |
34 |
23 |
107 |
82.6 |
33.3 |
M20 |
3/4 |
UC216-50 UC216 |
CF216 |
7.14 |
UCCF217-52 UCCF217 |
3-1/4
|
85 |
220 |
175 |
36 |
23 |
111 |
85.7 |
34.1 |
M20 |
3/4 |
UC217-52 UC217 |
CF217 |
8.38 |
UCCF218-56 UCCF218 |
3-1/2
|
90 |
235 |
187 |
40 |
23 |
122 |
96 |
39.7 |
M20 |
3/4 |
UC218-56 UC218 |
CF218 |
10.5 |
